| Type | 60SX | 80SX | 105SX | 115SX | 140SX | 150SX | 180SX | 190SX | 210SX | |
|---|---|---|---|---|---|---|---|---|---|---|
| Nominal cooling capacity | KW | 58.9 | 80.0 | 105.3 | 113.7 | 138.9 | 152.6 | 180.0 | 189.5 | 208.4 |
| 104kcal/h | 5.1 | 6.9 | 9.1 | 9.8 | 11.9 | 13.1 | 15.5 | 16.3 | 17.9 | |
| Run control | Use PLC microcomputer control | |||||||||
| Power Supply | 380V/3N/50HZ | |||||||||
| Startup type | Y-Δ | |||||||||
| Compressor | Type | SeMi-closed 5:6 asymmetric twin-screw compressor | ||||||||
| Refrigeration input power(kw) | 21.0 | 28.0 | 35.0 | 38.0 | 46.0 | 50.0 | 57.0 | 60.0 | 66.0 | |
| Rated Current(A) | 36.6 | 48.0 | 59.8 | 65.6 | 79.8 | 86.9 | 97.0 | 102.0 | 112.3 | |
| Energy regulation | 0-33%-66%-100% | 0-25%-50%-75%-100% | ||||||||
| Evaporator | Type | Pipe dry high efficiency heat exchanger | ||||||||
| Flow(m³/h) | 10.9 | 14.8 | 19.5 | 21.0 | 25.7 | 28.2 | 33.3 | 35.1 | 38.6 | |
| Water pressure drop(kpa) | 45.0 | 45.0 | 48.0 | 48.0 | 50.0 | 50.0 | 50.0 | 55.0 | 55.0 | |
| Interface size(mm) | DN50 | DN50 | DN80 | DN100 | DN125 | |||||
| Condenser | Type | Pipe high efficiency heat exchanger | ||||||||
| Flow(m³/h) | 13.8 | 18.6 | 24.1 | 26.1 | 31.8 | 34.9 | 40.8 | 42.9 | 47.2 | |
| Water pressure drop(kpa) | 42.0 | 42.0 | 45.0 | 45.0 | 48 | 48 | 48.0 | 52.0 | 52.0 | |
| Interface size(mm) | DN50 | DN50 | DN80 | DN100 | DN125 | |||||
| Refrigerant | Type | R22 | ||||||||
| Refrigerant volume(kg) | 14.8 | 20.5 | 27.3 | 29.6 | 36.4 | 39.8 | 46.6 | 48.9 | 53.4 | |
| Overall dimensions | Length(mm) | 2450 | 2450 | 2700 | 2850 | 2850 | 2850 | 2850 | 3250 | 3250 |
| Width(mm) | 660 | 660 | 660 | 890 | 890 | 920 | 920 | 920 | 960 | |
| Height(mm) | 1450 | 1590 | 1590 | 1600 | 1690 | 1690 | 1690 | 1690 | 1750 | |
| weight | Machine weight(kg) | 850 | 1050 | 1150 | 1270 | 1340 | 1430 | 1640 | 1710 | 1780 |
| Operating weight(kg) | 890 | 1140 | 1290 | 1410 | 1530 | 1660 | 1800 | 1840 | 1880 | |
